VME-VME64 6U Backplane – 162 Series
The 6U 162 Series boasts a variety of configurations to fit a complex array of needs. From 2 to 21 slots, optional active or passive termination and both VME and VME64x availability, there is an option for every need.
Product Description
VME-VME64 6U Backplane – 162 Series
- Form Factor 6U J1, 6U J2
- Slots 10, 12, 14, 16, 19, 2, 20, 21, 3, 4, 5, 6, 7, 8, 9
- Slot Pitch 4HP (20.32 mm)
- Power Consumption, Both Ends Terminated Active: <0.2A, Passive: < 1.3A
- Daisy Chaining/Bus Grant Electronic automatic (OR gate), Manual (jumper or wire wrap, on request), Mechanical automatic (switching connector)
- Power Supply Connection Screw-type M4 / Faston 6.3 x .8 mm
- Permissible Current Load/Terminal Bar 200A
- Permissible Current Load of Combined Double Spade/ Screw Connection 25A
- Permissible Current Load/Faston 10A
- Permissible Current Load Per Slot +5V 9.0A, +12V 1.5A, -12V 1.5A, +5VStandby 1.5A
- Termination ON/IN Board Active, Passive
- PCB Design Optimized for best HF behavior
- Base Specification ANSI/VITA 1.1-1997
- Base Material Type FR-4
- Ohmic Resistance < 1.5 Ohm
- Surge Impedance Z of Signal Lines 55 Ohm
- Chassis GND – Continuous chassis GND surface where backplane is mounted to rack., HF coupling of rack and system ground implemented by capacitors (10nF, 200V each slot). Chassis ground combination M6 screw / Faston 6.3 x .8 mm
- Card Thickness 3.2 mm (.13″)
- Connectors 96 pin, 2 mm press-fit, quality grade 2
- Operating Temperature Active: 0°C … +70°C, Passive: -40°C … +85°C
- Relative Humidity 90%, non-condensing
