6U VPX – OpenVPX Backplanes
The OpenVPX framework defines clear interoperability points necessary for integration between Module to Module, Module to Backplane and Chassis. OpenVPX recommends, but does not specify development systems to assist evaluation, prototype and development of VPX systems. OpenVPX will evolve and include new fabric, connector and system technology as newer standards are defined.
Product Description
6U VPX – OpenVPX Backplanes
- Form Factor 6U
- Slots 10, 12, 16, 5, 6
- Slot Pitch 5HP common
- Topology Centralized, distributed
- High Speed Design Up PCIe Gen3 /10 GbE
- Base Specification OpenVPX VITA 65/ VITA 46
- Impedance Controlled Yes
- PCB Thickness 5.4 mm
- Connectors MultiGig RT2 / Velox
