- Strike IV Mission Computer
- SFF SWaP-optimized 8.50”W x 13.25”D x 5.10”H
- Latest Intel mobile CPU, Standard: Xeon E-2276ML
- Latest NVIDIA embedded GPU, Standard: GeForce 1050Ti or Quadro RTX3000
- Up to 64GB dual-channel DDR4 (ECC with Xeon CPU)
- Base system IO: multiple GbE, USB 3.0, USB 2.0, serial, DVI, audio
Product Description
Strike IV Mission Computer Features
- SFF SWaP-optimized 8.50”W x 13.25”D x 5.10”H
- Latest Intel mobile CPU
- Standard: Xeon E-2276ML
- Latest NVIDIA embedded GPU
- Standard: GeForce 1050Ti or Quadro RTX3000
- Up to 64GB dual-channel DDR4 (ECC with Xeon CPU)
- Base system IO: multiple GbE, USB 3.0, USB 2.0, serial, DVI, audio
- Robust system expansion options including multi-port and multi-format video capture/encode, multi-port GbE switch/NIC, CAN, ARINC-429, 1553, GPS
- Dual high-capacity removable 2.5” SSDs; options for internal mSATA storage
- MOSA-aligned
Environmentals
- Fully rugged and sealed
- Operating temperature: -40C to +60C (configuration dependent)
- MIL-STD-810H Shock | Vibration | Altitude | Humidity | Sand and Dust | Fluids/Rain | Explosive Atmosphere
- MIL-STD-461G EMI/EMC
- MIL-STD-1275E/704F 28VDC Power (no power hold-up)
- DO-160G various
- IP66 sealed
