Renice H1 Plus CF card adopts standard IDE (50 pin) interface, the maximum capacity can reach 512GB, high reliable Read and Write performance, supports AES encryption, balance technology, data reading anti-interference management, overvoltage overcurrent protection and Power-off Protection and other special functions.
Product Description
CF Card Basic Information
- Form factor: 1.0inch (42.8 mm x 36.4 mm x 3.3 mm) L×W×H
- Interface：IDE（50 pin）
- Capacity：-MLC：4 GB~512 GB -SLC:1 GB~64 GB
- Input Voltage：3.3 V (±5%)
Performance
- Max Sequential Read/Write：90 MB/75 MB/s
- Write Endurance：>8年@ 100GB per day erase ( 32 GB SLC SSD)
- Read Endurance：JESD47 compliant
- Data Retention: JESD47 compliant
Flash Memory Management
- Flash Translation Layer (FTL) for high durability
- Flash Memory Management : Static, Dynamic and Global Wear leveling to maximize system write endurance
- Health-Monitoring and S.M.A.R.T.
- Hardware BCH ECC error correction: 96-Bit /1 KB
- Direct Flash Memory： Direct Flash Memory Access (DFA) co-processor incl. page buffers and interleaving capability
Special Functions
- Built-in power protection monitoring, over-voltage protection
- AES：AES-128 and AES-256 support with CBC and XTS modes, high performance on-the-fly encryption/decryption
Environment
- Temperature Range： Operation: -40~ +85℃, Storage: -40~ +125℃
- Humidity：5-95%
- Vibration：16.4 G (10-2000 HZ)
- Shock: 1500 G(@0.5 ms Half-sine wave,1 time / axis 50 G (@11 ms Half-sine wave, 3 times / axis)
